Foton 4*4 drive pickup wrecker can be used in the underground garage wrecker

This towing equipment is a game – changer for rescuing faulty vehicles in underground garages. Its foremost advantage lies in the fact that it eliminates the need for additional counterweights, which simplifies the operation process and reduces preparation time. This not only saves effort but also ensures that the vehicle’s front remains stable during towing, preventing any potential tilting that could cause safety hazards or damage to the towing vehicle. Chassis configuration: Foton Tunland  9 Heavy duty pickup chassis, total mass 3250kg, 3110 mm wheelbase, single row cab, diesel 2.5T engine, 4*4 drive, front double fork arm + rear leaf spring, near and far light integrated lens headlights, with LED daytime running lights, side turn signal (heavy duty regulation requirements), LT265/65R17 tires, Ordinary multi-function steering wheel + backlit buttons (FM + volume), Bluetooth, instrument page turning, 7 “color screen instrument, BOS brake priority, Automatic Emergency Braking (AEB), 4G-T-BOX, collision unlock, one-button start, ESP.   Upper configuration: the maximum effective length of the bracket is 1550mm, the L-arm can be installed automatically, and the maximum lifting mass of the bracket is 1000kg; Maximum pull of winch 2268kg The winch is equipped with a quick release device, which can realize the quick...

Learn more

Illustrated Diagram of Pickup Truck Towing System Installation Method

Remove the rear cargo box and spare tyre equipment. Welding and reinforce the inner side of the vehicle’s rear axle with steel spring plates Weld and fix the double cross beam bracket of the rear tow arm in the exact center of the rear axle. The position of the second cross beam is on the center of the rear wheel. The lengths of the two cross beams can be cut according to the actual installation size. Pay attention to making it horizontal when welding. Lift the rear end of the towing arm to the highest point off the ground. (lf the reinforced transverse beam at the rear end of the rear axle blocks the lifting cylinder, a U-shaped notch needs to be cut.) After adjusting the size of the place marked in red on the rear tow arm, weld and reinforce it. 6.The inclination angle of the articulated disc of the rear tow beam can be adjusted. (When adjusting, make it horizontal and then weld and reinforce it. 7.After opening a hole in the front left or right of the cargo box (according to the size of the control box) or put it in the cabin, install and fix the...

Learn more

Main Structure Schematic Diagram of Heavy – duty Towing and Lifting Integrated / Rotary Boom Type Wrecker

Main Structure Schematic Diagram of Heavy – duty Towing and Lifting Integrated / Rotary Boom Type Wrecker   Only the classification of medium – and heavy – duty wreckers according to the conventional configurations of the upper body is introduced here. Based on the functions of the upper – body configurations of wreckers, their structures can be divided into two major categories: the integrated towing and lifting type and the rotary boom type.   Main Structure Schematic Diagram of Wreckers (1) Non – rotary Crane Type:   1.Cab2.Warning lights,light brackets, clearance lights (including indoor alarm control device)3.Vehicle body4.Winch5.Steel cable6.Boom7.Hydraulic cylinder 8.Lifting and supporting device9.Hook10.Outriggers11.Operation panel12.Multi – way valve and hydraulic system13.Fuel tank14.Toolbox and accessories15.Oil pump16.Power take – off (PTO)17.PTO operation switch18.Counterweight block19.Cable – guiding device 20.Pneumatic – electrical interface   (2)、Rotary Crane Type:         1.Cab; 2.Warning lights and their mounts, 2.clearance lights (including the indoor alarm control device); 3.Winch – equipped vehicle body; 4.Steel cable; 5.Boom; 6.Hydraulic cylinder; 7.Boom bracket; 8.Rope – guiding device; 9.Hook; 10.Lifting and supporting device; 11.Pneumatic – electrical interface; 12.Rear operation panel; 13.Rear outriggers;14. Main operation panel; 15.Multichannel valve and hydraulic system; 16.Fuel tank; 17.Boom slewing device; 18.19.Accessories like tow forks and brackets;20.21. Wireless and wired...

Learn more

Assemblable modular design tow-and-hoist integrated 10-ton wrecker upper body 2200-pound wrecker body kit

We are specialized in the production and export of wrecker superstructures. Take our 10-ton integrated towing and lifting wrecker superstructure as an example. Our product range covers capacities from 3 tons to 100 tons, with various models available, such as flatbed wreckers, pickup truck wreckers, integrated towing and lifting wreckers, and rotating wreckers.

Learn more

howo 3ton flatbed tow truck

howo chassis,3ton towing capacity ,4.2m length flatbed tow truck, yunnei diesel engine, 25m steel wire,euro2 emission standard, left hand or right hand steering, 3ton towing capacity, used for road rescue, heavy duty machine transportation

Learn more

shacman heavy duty 20ton rotator crane tow truck

shacman chassis,20ton towing capacity ,hydraulic winch, weichai diesel engine,euro2 emission standard, left hand or right hand steering, 70ton rear arm capacity, used for road rescue, heavy duty machine transportation
