Chassis Configuration
- Wheelbase: 3360mm, providing a stable and balanced structure for the vehicle during transportation.
- Engine: 4KK1N6LB Qingling Isuzu, a 2.5L in – line four – cylinder engine, delivering 130 horsepower. This engine ensures a consistent and reliable power output, making it ideal for the demands of daily bulk feed transportation.
- Transmission: Isuzu 5 – speed manual transmission. It offers a smooth and precise shifting experience, high transmission efficiency, and a perfect match with the engine, allowing for efficient power transfer.
- Tire Model: 7.00R16 8PR, providing sufficient traction and load – bearing capacity for various road conditions.
- Other Configurations: The vehicle is equipped with a KV100 single – row cab, featuring a spring – applied parking brake.This brake system ensures safety in case of braking system failures. Additionally, it comes with power steering for easier driving, air conditioning to create a comfortable driving environment, electric windows for convenient operation, and an ABS system. The ABS prevents wheel lock – up during braking, enhancing vehicle stability and controllability.
Body Configuration
Manufacturing Process
The body is crafted using a vacuum – adsorption and hydraulic – adsorption integrated production line. With the sandwich composite bonding technique, its heat – preservation performance meets the national Class A standard. This advanced manufacturing process ensures the durability and excellent insulation properties of the body.
Body Panel Material
- The inner and outer wall panels are made of high – quality domestic FRP (Fiberglass – Reinforced Plastic). FRP has remarkable properties such as non – light – absorption, outstanding heat insulation, high hardness, and strong oxidation resistance.
- The middle part is filled with a high – performance heat – preservation board, and the overall body thickness is 8CM.
- The floor is made of one – piece FRP board, and the door edge strips use maze – type rubber sealing strips, which effectively prevent air leakage and ensure the integrity of the temperature – controlled environment inside the body.
Body Accessories
- The body is surrounded by aluminum alloy edging, adding a touch of elegance and durability. Stainless – steel corner guards, door locks, door frames, and hinges are used, which are highly resistant to corrosion and wear.
- Energy – saving LED lights are installed inside the body, providing bright and efficient lighting for easy inspection and operation.
Constant – temperature Equipment
The Xinkaili constant – temperature refrigeration unit, model KL700, comes with a heating function. This unit can precisely regulate the temperature inside the body, ensuring that the feed is always stored in an optimal temperature environment, regardless of external weather conditions.
Ventilation Equipment
- There are a total of 8 openable ventilation windows on both sides of the body, allowing for natural air circulation.
- Four exhaust fans are installed on the top and four on the tailgate. Additionally, there are ventilation ducts on both sides of the upper part of the body and an electric louver inlet at the front. The floor is equipped with detachable stainless – steel ventilation ducts, which can be easily cleaned and maintained. This comprehensive ventilation system effectively exchanges air, preventing the growth of mold and bacteria in the feed.
Flipping Shelves
Manual flipping cargo – stacking shelves are installed on both sides of the body. These shelves are convenient for loading and unloading feed, improving the efficiency of transportation operations.
Control Equipment
The vehicle is equipped with a liquid – crystal touch – control assembly. This modern control system allows for easy and intuitive operation, enabling the driver to monitor and adjust various functions of the vehicle with ease.
Probes
A carbon dioxide sensor and 2 temperature probes are installed. These probes can accurately monitor the carbon dioxide concentration and temperature inside the body, providing real – time data for maintaining the quality of the feed.
In summary, this Isuzu bulk feed transportation vehicle combines a powerful chassis and a well – equipped body. It is designed to meet the high – efficiency and high – quality requirements of bulk feed transportation, ensuring the safe and stable delivery of feed.
