1.5cbm water tank, 4cbm dirty tank,isuzu chassis, euro4/5/6 emission standard, left or right hand steering, max sweeping width 3.5m,working speed 5-20km/h,stainless steel material,with strong hydraulic system and CAN electric control system
1.5cbm water tank, 4cbm dirty tank,isuzu chassis, euro4/5/6 emission standard, left or right hand steering, max sweeping width 3.5m,working speed 5-20km/h,stainless steel material,with strong hydraulic system and CAN electric control system
| Truck name | isuzu road sweeper truck |
| Chassis parameters | |
| chassis brand | isuzu |
| Emission standard | Euro 4/5/6 |
| Driving type | 4*2 left hand or right hand steering |
| Tire specification | 7.00R16 6 wheels +1 spare tire |
| Wheel base | 3300 mm |
| Engine | isuzu |
| Front axle capacity | 2.4ton |
| Rear axle capacity | 4.8ton |
| Transmission gearbox | 5 gears |
| Air condition | Heat and cold air conditioning |
| Super structure parameters | |
| Container volume | 1.5m³ water container+4 m³ garbage container |
| Container material | High strength carbon steel(water container) |
| Stainless steel (garbage container) | |
| Sweep Brush | 4 units |
| Sucker | Bottom -installed |
| max sweeping width/h | 3.5m |
| working speed | 5-20 km/h |
