dongfeng 5ton small water tanker truck

dongfeng chassis,98hp diesel engine, 3300mm wheel base,5ton loading capacity,stainless steel/carbon steel tank material, water pump/stainless steel water pump, rear working platform ,used for street washing, water storage,etc

Technical Data

Truck name dongfeng 5m³ water sprinkler truck
Chassis parameters
Chassis brand dongfeng
Emission standard Euro 2/3//6
Driving type 4*2
Steering type Left /right hand
Cab model One row with bed
Tire specification 7.00R20
Tire number 6wheels+1 spare tire
Wheel base 3300mm
Engine chaochai
Horsepower 98hp
Front axle capacity 2ton
Rear axle capacity 4ton
Transmission gearbox 5 gears
Suspension Leaf spring
Air condition Heat and cold air conditioning
Super structure parameters
Container volume 5 m³
Container material High strength carbon steel
water Sprinkling width 12m
Sprinkling width 28m
the depth of water uptake 7m
working speed 22km/h

Application
