dongfeng chassis,190hp diesel engine, 4500mm wheel base,12000L loading capacity,stainless steel/carbon steel tank material, water pump/stainless steel water pump, rear working platform ,used for street washing, water storage,etd
| Truck name | Dongfeng 12000l water sprinkler truck |
| Chassis parameters | |
| Chassis brand | dongfeng |
| Emission standard | Euro 2/5/6 |
| Driving type | 4*2 |
| Steering type | Left /right hand |
| Cabin model | One row |
| Tire specification | 9.00R20 |
| Tire number | 6 wheels+1 spare tire |
| Wheel base | 4500 mm |
| Engine | cummins |
| Horsepower | 190hp |
| Front axle capacity | 6ton |
| Rear axle capacity | 10ton |
| Transmission gearbox | 6 gears |
| Oil tank volume | 160L |
| Suspension | Leaf spring |
| Air condition | Heat and cold air conditioning |
| Super structure parameters | |
| Container volume | 12 m³ |
| Container material | carbon steel/stainless steel |
| water Spraying height | 35m |
| Spraying width | 28m |
| the depth of water uptake | 7m |
| working speed | 22km/h |
