FAW chassis,130hp diesel engine, 4200mm wheel base,10ton loading capacity,stainless steel/carbon steel tank material, water pump/stainless steel water pump, rear working platform ,used for street washing, water storage,etd
The sprinkler is loaded with a front rush, after sprinkling, side spray, rear type working platform, platform with high pressure water cannon (360° rotation, water mist shape can be adjusted into straight rush shape, heavy rain, moderate rain, light rain, drizzle)
Equipped with high quality high-power special sprinkling pump,famous brand force extractor, sundry filter, GB general 65 fire interface (water can be added through fire hydrant), a set of self-flow ball valve system, self-suction and self-discharge, installation of 2 water diversion steel wire hose.
Suitable for all kinds of road cleaning; city virescence belt watering; construction site,and high - altitude building flushing. It has many functions such as water sprinkling, dust pressing, high (low) level spraying, pesticide spraying, guardrail washing and emergency fire fighting.
| Truck name | FAW 10000l water tank truck |
| Chassis parameters | |
| Chassis brand | FAW |
| Emission standard | Euro 2/5/6 |
| Driving type | 4*2 |
| Steering type | Left /right hand |
| Cab model | One row |
| Tire specification | 8.25R20 |
| Tire number | 6 wheels+1 spare tire |
| Wheel base | 4200 mm |
| Engine | yuchai |
| Horsepower | 130hp |
| Transmission gearbox | WLY6T115 |
| Suspension | Leaf spring |
| Air condition | Heat and cold air conditioning |
| Super structure parameters | |
| Container volume | 10 m³ |
| Container material | High strength carbon steel |
| Hydraulic assy | Domestic famous brand |
| Operation assy | Two sides simultaneous operation |
| Remote control | optional |
| Tank thickness | 4mm |
| Spraying model | Front spraying, rear spraying,two sides spraying |
| Spraying capacity | Front spraying>18m |
| High pressure spraying>35m | |
